Bläk 737 Paris

Fixed shower screen

Fixed shower screen protects the space and the fixture next to the shower from splashing water. Fixed shower screen is sturdy and can be efficiently used for protection from water.

The wall mounting profile is screwed in to the building wall. The fixed shower panel with a tuning leg set up on the bottom is attached to the wall mounting profile with self-drilling screws. The support bar is set up from the top edge of the fixed panel and screwed into the building wall. A bottom seal can be attached to the shower panel to improve water retention. Installation guide

Installation
Icon

12 Working days

Icon

20 year warranty

The white (RAL 9016) and black (RAL 9005) surface treatment options are manufactured by powder coating. The fittings used in the product, like square foot and brace bars, are brass alloy painted black/white.

The product is manufactured of 6mm thick tempered safety panel (EN 12150). The safety panel can be treated in the factory with Cranith calcification prevention coating. The coating enables the panel to stay clean easier. One side of the satin panel is etched to acquire a velvety feel and the other side is smooth. When choosing a satin panel product, bear in mind that the etched surface of the panel is sensitive to scratches and stains.

The size of the shower screen can be selected from the standard dimensions or it can be manufactured custom dimensions. wall mounted profiles have 7mm of adjustment range. The adjustment range can be used for levelling any tilt of the building’s wall or for extension of the width of the shower screen in relation to the provided standard dimensions. The width can be further extended by 40mm via the extension profile (optional accessory). The extension profile can be grooved, for example, for the inlet of the surface water pipes. The fixed panel is mounted with tuning leg by default which is suitable for tilted floors in the case of even floor the floor mounted option can be selected.

Product size

Fixed shower screen (L1)

X

The total width of the selected product is:
- At its narrowest: 697mm
- At its widest: 704mm
Dimensions may deviate from the declared values if adjustment tolerance must be used to level the tilt of the building’s walls.:


Product

Product code

Price

1

Bläk 737 Paris

Product code

737-61-B

Price

0.00 €

2

Bläk 711 Fixed shower screen
White painted/Transparent/L1=697 x 1950

Product code

711 61 0069

Price

480.00 €

3

Paris -frame

Product code

703 RL 0011

Price

220.00 €

4

Side seal

Product code

719 RL 0011

Price

0.00 €

5

Grid placement Paris /

Product code

781 RL 0011

Price

0.00 €

6

Bläk -campaign -20%

Product code

DISCOUNT

Price

-96.00 €

7

TOTAL

Product code

Price

604.00 €

The total width of the selected product is:
- At its narrowest: 697mm
- At its widest: 704mm
Dimensions may deviate from the declared values if adjustment tolerance must be used to level the tilt of the building’s walls.:

EAN:
